Street Turbo Billet Compressor Wheel High quality GT25 GT28 GT2871 GT2860 AR.60 .64 Water+Oil Cooling

SKU

3002050576

Skip to the beginning of the images gallery

Application

Universal for Turbo Manifold with T25 Flange(T28 Flange can be converted to T25 Flange, Adrapter is needed).
\ Perfect for all 1.5L-2.0L engine，for all 4 cylinder engine

Specification

Exhaust Inlet Flange: Standard T25 Flange
\ Exhaust Outlet Flange: 5-Bolt
\ Turbine Side:
\ Turbine Trim: 76.3
\ Turbine A/R: 0.64
\ Turbine Inducer Diameter: 53.8mm
\ Turbine Exducer Diameter: 47mm
\ Compressor Side:
\ Compressor Trim: 48
\ Compressor A/R: 0.60
\ Compressor Inducer Diameter: 49.2mm
\ Compressor Exducer Diameter: 71 mm
\
\ Bearing Type: Wet Float
\ Cooling Type: Water + Oil Cooled
\ Thrust Bearing: 270 Degrees
\ Internal Wastegate: Yes
\ Oil Restrictor: Yes
\ Oil Restrictor size：inside diameter 2mm
\ Oil Thread Size: M8*1.25
\ Water Thread Size: M14*1.5
\ Horse Power: Boost Horse Power up to 350BHP
\ Turbo Type: Individual
\ Universal Fitment: Yes
\ Finish:Matte
\ Condition: 100% Brand New
\ Accessories: You will get exactly as shown as picture above
\ package size：26x24x22cm
\ package weight：7250g

Package included

1xTurbocharger
\ 1xFlange gasket
\ 2xOil/Water port gaskets
\ 1xBolt
\ 1xOil restrictor
\ 1xManual
\ 1xBrochure
\ 1xSticker

Feature

*Product Material
\ 1. Turbine housing ：Silicon-Molybdenum - temperature resistant up to 850℃
\ 2. Steel Turbine Wheel：K419 alloy - high oxidation stability and resistance up to 1000℃
\ 3. Compressor housing：ZL104 aluminum with lightweight
\ 4. Billet compressor wheel：forged full-machined billet aluminum compressor wheels with a larger horsepower range and better boost response
\
\ *Product Performance
\ 1. Increase 20-40% power for your car
\ 2. Excellent high temperature resistance，high efficiency and durability
\ 3. Rich experience in turbo production and own factory
\ 4. High-Speed oil seal ring and Precision clearance
\
\ * Technology Advantage:
\ 1. 100% balancing Test by TURBOTECHNICS VSR3
\ 2. G3-min-Flow VNT Turbo testing
\ 3. Advanced Actuator Tester/Programmer

Note

* Replace, repair or reconnect air cleaner element per manufacturer's manual to avoid compressor wheel damage.
\ * Make sure the oil drain line is lower than the turbo itself.
\ * Gasoline car must install a water cooling device to avoid overheating.
\ * Ensure exhaust outlet are well sealed by welding
\ * The degree of modification of the universal turbo depends on your individual vehicle.Professional installation is highly recommended.
\ * This Turbo is not vehicle specific. Please check the specifications and verify compatibility prior to placing your order.
\ * Before installing the new turbocharger, the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!
