Compatible for Volvo B230 152mm Connecting Rod Con Rod Conrod ARP 2000 Bolts Sale

SKU
3002032912

Register and log in to view the price.

Compatible for Volvo B230 152mm Connecting Rod Con Rod Conrod ARP 2000 Bolts Sale
CR-Compatible for Volvo-152
CR-Compatible for Volvo-152
High Quality Components
High Quality Components
With Standard ARP 2000 Bolts (Upgradable ARP L19)
Precision Machining Manufacturing
Precision Machining Manufacturing
Shot Peening for improved fatigue life. 100% CNC machined for superior tolerances,Precision rod cap alignment dowels
Professional H-Beam Design
Professional H-Beam Design
Improve stiffness, reduce stress risers and reduce weight
High Performance Material
High Performance Material
Forged 4340 aircraft chrome moly quality steel for racing.Advertised Horsepower Rating:800HP

Application

Compatible for Volvo B230 engines
Compatible for Volvo 740 1984–1992 B230 engines 2.3
Compatible for Volvo 760 1982–1990 B230 engines 2.3
Compatible for Volvo 940 1990–1998 B230 engines 2.3
Compatible for Volvo 240 1983–1993 B230 engines 2.3
(Note: Please confirm the dimensions before purchase the connecting Rods)

Specification

- Performance Con Rods
- Type: Forged 4340 aircraft chrome moly quality steel
- H-beam Conrods Quantity: 4 Pieces as showing in picture
- Bolts: Including ARP 2000 bolts
- Note: Extra cost for upgrading to ARP L19 bolts
- Bolts Size: ARP 2000 3/8" bolts
- Tolerance: Balanced to +/- 1 gram in set
- Piston Bolt Hole: +-4/1000mm
- Power: 600hp ~ 800PS per set
- Strength of the fastening (PSI): 220,000/230,000 PSI Torque: 48ft ≈ 65 NM
- Top acceleration: 9000rpm
- Warranty: one year warranty for any manufacturing defect

Dimensions

Center to center length:152mm/5.984"
Big end diameter:52mm/2.047"
Small end diameter:23mm/0.906"
Big end width:24.8mm/0.976"
Small end width:24.8mm/0.976"

Feature

- Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
- Designed and processed by CNC machine.
- All big and small ends are finished with SUNNEN honing machine
- Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk
- 100% X-rayed, sonic tested and magnafluxed
- Multi-stage heat treated
- Shot peened to relieve stress
- Come with the bronzed bushing suitable for the floating piston pin

Note

- Professional installation is highly recommended (No Instruction Included)
- Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
